N Female to SMA Female 4H Flange Adapter
₹272.50
N Female to SMA Female 4H Flange Adapter connects dissimilar RF connectors with precision. Perfect for telecom, lab testing, and RF systems. Ensures signal integrity and durability.
Product successfully added to the Quote List
| Quantity | Price | Discount |
|---|---|---|
| 100-199 | ₹261.60 | 4% |
| 200-499 | ₹250.70 | 8% |
| 500-999 | ₹245.25 | 10% |
| 1000+ | ₹239.80 | 12% |
| Frequency Range |
DC-6 GHz |
|---|---|
| Impedance |
50Ω |
| VSWR |
≤ 1.2@4GHz |
| Insertion Loss |
≤0.15 dB |
| Body & Plating |
Brass ,Nickel plated |
| Center Contact |
Gold Plated ,Phosphor Copper |
| Insulator |
PTFE |
| Durability (matings) |
≥500 |
| Compliance |
ROHS |
| Operating Temperature(℃) |
-20 to +80 |
